Camera

Image Sensor

1/4 AR0130+NXP2431

Effective   Pixels

1080*960

Electronic   Shutter

1/50s~1/100,000s

Video Frame   Rate

PAL: 25fps@1080P;   NTSC: 30fps@1080P

Synchronization

Internal

Min.   Illumination

0.01Lux@F1.2(AGC   ON), 0Lux IR on

Video Output

1 CH BNC AHD   high definition video output

Camera Features

LEDs

24*Φ5

IR Distance

20-25m IR view

Day/ Night

Auto(ICR) /   Color / B/W

Noise   Reduction

2D

Lens

Focal Length

3.6/6mm

Mount Type

CS

General

Power Supply

DC12V±20%

Power   Consumption

Max 2.5W

Working   Environment

-30°C~+60°C /   Less than 95%RH (no condensation)

Transmission   Distance

Over 500m via   75-3 coaxial cable

Ingress   Protection

IP65

Material

Metal
